Preface
About This Guide
The XtremeDSP? Development Platform: Spartan-3A DSP 3400A Edition User Guide provides
instructions for designing and accelerating the development of new products. The
XtremeDSP Development Platform: Spartan-3A DSP 3400A Edition board is an excellent
medium for consumer-oriented wireless and multimedia video applications, where cost-
efficient solutions are essential. Throughout the remainder of this guide, the development
board may be referred to as both the XtremeDSP Development Platform: Spartan-3A DSP
3400A Edition board and the Spartan-3A DSP 3400A Edition board.
Guide Contents
The User Guide contains the following chapters:
?
?
?
?
?
Preface, “About this Guide” introduces the organization and purpose of the User
Guide and the conventions used in this document.
Chapter 1, “Introduction,” identifies the major components, parts, and functionality
of the Spartan-3A DSP 3400A Edition board.
Chapter 2, “Configuration Options,” provides an overview of the four configuration
methods available on the FPGA on the Spartan-3A DSP 3400A Edition board.
Chapter 3, “Programming the IDT Clock Chip,” provides step-by-step instructions for
using the IDT software to generate a combination of clock frequencies and implement
them on the development board.
Appendix, “Technical Specifications,” identifies the Spartan-3A DSP 3400A Edition
board technical specifications.
Additional Resources
To find additional documentation, see the Xilinx website at:
www.xilinx.com/support/documentation
To search the Answer Database of silicon, software, and IP questions and answers, or to
create a technical support WebCase, see the Xilinx website at:
http://www.xilinx.com/support .
Spartan-3A DSP 3400A Edition User Guide
UG498 (v2.2) November 17, 2008
www.xilinx.com
